| Part Number | 5350607 |
| Previous Version | 19700523D, 2836368, 2836369, 2836373, 2838786, 2838787, 2838788, 2838791, 2840539, 2840540, 2840541, 2840544, 2840545, 2840548, 2840549, 2840550, 2881791, 2881791NX, 2881791RX, 2881792, 2881792NX, 2881792RX, 2881793, 2881793NX, 3774353, 3774354, 3774355, 3774356, 3774358, 3774623, 3774624, 3774637, 3774638, 3774650, 3775131, 3775132, 3775141, 3775650, 3776837, 3776838, 3776839, 3792242, 3792244, 3792246, 3792247, 3792247NX, 3792247RX, 3792248, 3792250, 379225000HX, 3792250H, 3792250HX, 3792251, 3795128, 3795150, 3795151, 3795152, 3797541, 3797542, 379754200, 3797542HX, 4039980, 4040648, 4040649, 4040650, 4040651, 4042426, 4042428, 4042430, 4042432, 4044519, 4044520, 4045268, 4045269, 4046226, 4046227, 4309083, 4309083NX, 4309083RX, 4309124, 430912400, 4309124NX, 4309124RX, 4955428, 4955428NX, 4955429, 4955429NX, 4955582, 4956026, 4956026NX, 4956027, 4956027NX, 4956028 |
| OE Number | 4956C26, 4955428 |
| Year | 2006-14 |
| Description | Industrial Crane |
| Manufacturer Part Number | 5350526, 5350607, 5350627, 5350627NX, 5350627RX, 5350629, 5355262, 5355263, 5355264, 5355981NX, 5359981, 5359981RX, 5455669, 5456971, 545697100, 545697100H, 545697100HX, 5456971H, 5456971HX, 5457032, 5457032H, 5457032HX, 5457203, 5457203NX, 5457203RX, 5458510, 5458510NX, 5458510RX, 5458511, 5458511NX, 5458511RX |
| Turbo Model | HE451Ve, HE400VG |
| CHRA | N/A |
| Engine | ISC, ISL, B3, B4, ISM |
| Engine Manufacturer | Cummins |
| Displacement | 320V |
| Fuel | Diesel |
| Angle α (compressor housing) | 257º |
| Angle β (turbine housing) | 158º |
| Turbine Wheel | 2840238RX (Ind. 66.35 mm, Exd. 71.28 mm, 11 Blades) |
| Comp. Wheel | (Ind. 61.95 mm, Exd. 92.96 mm, 7+7 Blades, Superback) |
| Turbine Housing AR | VGT |
| Speed Sensor Kit | 4034201H |
| Electronic Actuator Kit | 4034289 (28087185, 28087185-10, 2808718510, 28169119, 28169119-10, 2816911910, 2835940, 2837201, 3789667, 3789676, 3789677, 3791991, 379199100, 4032066, 4032673, 4032760, 4032760NX, 4032760RX, 4034116, 4034208, 4034210, 4034210NX, 4034210RX, 4034289, 403428900, 403428900HX, 4034289H, 4034289HX, 4034289NX, 4034289RX, 4034403, 4034403NX, 4034403RX, 4042307, 4043340, 4045108, 4045991)(12 Volts) |
| Electronic Actuator | 4034290H (24V) Reman |
| Gasket (turbine inlet) | 3088984 |
| Gasket Kit | 3685535 |
2006-14 Cummins (CTT) Industrial Crane with ISC, ISL, B3, B4, ISM Engine
